4.2.8 Status Register 2 (STAT2)
The Status Register 2 holds status information related to the rear I/O configuration.
4.2.9 Board ID High Byte Register (BIDH)
Each Kontron board is provided with a unique 16-bit board-type identifier in the form of a
hexadecimal number.
Table 4-10: Status Register 2 (STAT2)
REGISTER NAME STATUS REGISTER 2 (STAT2)
ADDRESS 0x287
BIT NAME DESCRIPTION
RESET
VALUE
ACCESS
7 - 6 Res. Reserved 00 R
5 - 4 RCFG Rear I/O configuration:
00 = Rear I/O disabled (CP3003-SA front I/O version)
01 = COMA, GPIO
10 = Reserved
11 = COMA, COMB
The default value depends on the CP3003-SA version ordered (front
I/O or rear I/O) and the rear I/O module used.
N/A R
3 - 0 Res. Reserved 0000 R
Table 4-11: Board ID High Byte Register (BIDH)
REGISTER NAME BOARD ID HIGH BYTE REGISTER (BIDH)
ADDRESS 0x288
BIT NAME DESCRIPTION
RESET
VALUE
ACCESS
7 - 0 BIDH Board identification:
CP3003-SA: 0xB3E0
0xB3 R
Note ...
The Board ID Low Byte Register is located in the address 0x28D.
