CP3003-SA Power Considerations
ID 1052-6929, Rev. 3.0 Page 5 - 7
D R A F T — F O R I N T E R N A L U S E O N L Y
The following tables indicate the typical power consumption of the CP3003-SA with 4 GB DDR3
SDRAM in dual-channel mode. The measurements were made with the CP3003-SA in uEFI
shell mode as well as with the Windows® 7 operating system, 64-bit.
Table 5-4: CP3003-SA in EFI Shell
NOMINAL
VOLTAGE
Core™ i7-3612QE (SV)
2.1 GHz
Core™ i7-3555LE (LV)
2.5 GHz
Intel® Core™ i7-3517UE (ULV)
1.7 GHz
5 V 6.5 W 6.5 W 5.0 W
3.3 V 10.0 W 9.5 W 9.0 W
Total 16.5 W 16.0 W 14.0 W
Table 5-5: CP3003-SA with Win. 7 and Processor and Graphics in Idle State
NOMINAL
VOLTAGE
Core™ i7-3612QE (SV)
2.1 GHz
Core™ i7-3555LE (LV)
2.5 GHz
Intel® Core™ i7-3517UE (ULV)
1.7 GHz
5 V 3.5 W 3.5 W 3.5 W
3.3 V 8.5 W 8.5 W 8.5 W
Total 12.0 W 12.0 W 12.0 W
Table 5-6: CP3003-SA with Win. 7 and Max. Proc. Workload and Basic Graphics Operation
NOMINAL
VOLTAGE
Core™ i7-3612QE (SV)
2.1 GHz
Core™ i7-3555LE (LV)
2.5 GHz
Intel® Core™ i7-3517UE (ULV)
1.7 GHz
5 V 21.0 W 13.0 W 8.5 W
3.3 V 9.0 W 8.0 W 7.5 W
Total 30.0 W 21.0 W 16.0 W
Table 5-7: CP3003-SA with Win. 7 and Max. Processor and Graphics Workload
NOMINAL
VOLTAGE
Core™ i7-3612QE (SV)
2.1 GHz
Core™ i7-3555LE (LV)
2.5 GHz
Intel® Core™ i7-3517UE (ULV)
1.7 GHz
5 V 34.0 W 25.0 W 17.0 W
3.3 V 15.0 W 15.0 W 14.0 W
Total 49.0 W 40.0 W 31.0 W
Note ...
The Intel® Core™ i7-3517UE (ULV) 1.7 GHz processor provides a software-
configurable Thermal Design Power (TDP) that allows for reduction of the pow-
er consumption by up to 3.0 W at a nominal voltage of 5 V. For information on
this feature, refer to the CP3003-SA uEFI BIOS User Guide, “kboardconfig”
uEFI Shell command.
