Installation CP3003-SA
Page 3 - 14 ID 1052-6929, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
Figure 3-8: CP3003-SA Board with CP3003-XMC Extension Module and XMC Module
Figure 3-9: CP3003-SA with Front Panel, CP3003-XMC Extension Module and XMC Module
XMC Module
CP3003-XMC
Extension Module
CP3003-SA Board
