B.5 CP3003-XMC Module Layout
Figure B-3: CP3003-XMC Module Layout (Top View)
Figure B-4: CP3003-XMC Module Layout (Bottom View)
CFast
HDD LED & Reset Button
D1
S1 PC1 PC17S7
J2
J1
A1
F1
A19 F19
J5
J6
