2.2 Memory
The CP3003-SA supports a dual-channel (72-bit) DDR3 memory with Error Checking and Cor-
recting (ECC) running at 1600 MHz. It provides two 204-pin sockets for two DDR3 ECC SO-
DIMM modules that support up to 16 GB system memory. The maximum memory size per
channel is 8 GB. The available memory module configuration can be either 4 GB, 8 GB or
16 GB. However, when the internal processor graphics controller is enabled, the amount of
memory available to applications is less than the total physical memory in the system. For ex-
ample, the chipset’s Dynamic Video Memory Technology dynamically allocates the proper
amount of system memory required by the operating system and the application.
Table 2-1: Features of the Processors Supported on the CP3003-SA
FEATURE
Core™ i7-3612QE (SV)
2.1 GHz
Core™ i7-3555LE (LV)
2.5 GHz
Core™ i7-3517UE (ULV)
1.7 GHz
Processor Cores four two two
Processor Base Frequency 2.1 GHz 2.5 GHz 1.7 GHz
Maximum Turbo Frequency 3.3 GHz 3.2 GHz 2.8 GHz
L1 cache per core 64 kB 64 kB 64 kB
L2 cache per core 256 kB 256 kB 256 kB
L3 cache 6 MB 4 MB 4 MB
DDR3 Memory up to 16 GB / 1600 MHz up to 16 GB / 1600 MHz up to 16 GB / 1600 MHz
Graphics Base Frequency 650 MHz 550 MHz 350 MHz
Graphics Max. Dynamic
Frequency
1.0 GHz 950 MHz 950 MHz
Thermal Design Power 35 W 25 W 17 W
Note ...
Only qualified DDR3 ECC SODIMM modules from Kontron are authorized for
use with the CP3003-SA. Replacement of the SODIMM modules by the cus-
tomer without authorization from Kontron will void the warranty.
