D. SATA Flash Module
The 4 HP CP3003-SA provides an optional SATA Flash module with up to 32 GB NAND flash
memory. The SATA Flash module is connected to the CP3003-SA via the J12 connector
located on the CP3003-SA and the J1 connector located on the SATA Flash module. The SATA
Flash module has been optimized for embedded systems providing high performance,
reliability and security.
D.1 Technical Specifications
Note ...
Write protection is available for this module. Please contact Kontron for further
assistance if write protection is required.
Note ...
If the SATA Flash module is mounted on the CP3003-SA, the Smart Extension
Module, the CP3003-HDD module or the CP3003-XMC module cannot be
used with the CP3003-SA.
Table D-1: SATA Flash Module Specifications
SATA FLASH MODULE SPECIFICATIONS
Interface
Board-to-Board Connector One 18-pin, female, board-to-board connector, J1
Memory
Memory Up to 32 GB SLC-based NAND flash memory
• Built-in full hard disk emulation
• Up to 60 MB/s read rate
• Up to 55 MB/s write rate
General
Power Consumption typ. 0.5 W
3.3 V supply
Temperature Range Operational: 0°C to +60°C Standard
-40°C to +85°C Extended
Storage: -40°C to +85°C
Climatic Humidity 93% RH at 40°C, non-condensing (acc. to IEC 60068-2-78)
Dimensions 38 mm x 27 mm
Board Weight ca. 6 grams
