Kontron CP3003-SA - 12 HP CP3003-SA with CP3003-HDD Module and SATA Adapter Module; HP CP3003-SA with CP3003-XMC Module

Installation CP3003-SA
Page 3 - 10 ID 1052-6929, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
Figure 3-4: 12 HP CP3003-SA with CP3003-HDD Module and SATA Adapter Module
Figure 3-5: 8 HP CP3003-SA with CP3003-XMC Module
The following chapters provide information regarding installation aspects of peripheral devices.
7-pin SATA
Cable Connector
CP3003-HDD
Module
SATA Adapter
Module
2 x 2.5” SATA HDD/SSD
CP3003-XMC
Module
CFast Card
XMC Module
(optional)
XMC
Con.
