F.3 Processor
The 2
nd
generation Intel® Celeron® 807UE processor used on the CP3003-V includes an in-
tegrated Intel® HD Graphics controller and a DDR3 single-channel memory controller with
ECC support. It supports various technologies, such as:
• Intel® Enhanced SpeedStep® Technology
• Intel® Streaming SIMD Extensions 4.1
• Intel® Streaming SIMD Extensions 4.2
• Intel® 64 Architecture
• Execute Disable Bit
• Idle States
• Intel® Virtualization Technology (Intel® VT-x)
• Thermal Monitoring Technologies
• Intel® Fast Memory Access
• Intel® Flex Memory Access
F.3.1 Integrated Processor Graphics Controller
The 2
nd
generation Intel® Celeron® 807UE processor includes a highly integrated processor
graphics controller delivering high-performance 2D graphics capabilities. The integrated
processor graphics controller has three independent display pipes allowing for support of
multiple display configurations.
The CP3003-V provides digital display support for resolutions up to 2560 x 1600 pixels @ 60
Hz (up to 2560 x 1600 pixels @ 60 Hz through DisplayPort and up to 1920x1200 pixels @ 60Hz
using HDMI/DVI). In addition, the CP3003-V provides analog display support for resolutions up
to 2048 x 1536 pixels with 32-bit color @ 75 Hz.
Table F-2: Features of the Intel® Celeron® 807UE Processor
FEATURE
Intel® Celeron® 807UE
1.0 GHz
Processor Cores one
Processor Base Frequency 1.0 GHz
Intel® Smart Cache (L3) 1 MB
DDR3 Memory up to 4 GB / 1333 MHz
Graphics Base Frequency 350 MHz
Graphics Max. Dynamic Frequency 800 MHz
Thermal Design Power 10 W
Table F-3: Maximum Resolution in 3-Display Configurations
DIGITAL PORT DIGITAL PORT ANALOG PORT
DisplayPort
2560x1600 pixels @ 60Hz
DisplayPort
1920x1200 pixels @ 60Hz
VGA Port
1920x1200 pixels @ 60Hz
HDMI/DVI
2560x1600 pixels @ 60Hz
via a cable adapter
HDMI/DVI
1920x1200 pixels @ 60Hz
via a cable adapter
VGA Port
1920x1200 pixels @ 60Hz
