F. CP3003-V
F.1 Overview
Optimized for reduced costs delivering maximum value, the CP3003-V combines the capabili-
ties of an all-in-one industrial PC with the advantages of a robust 3U CompactPCI® design.
The board is based on the CP3003-SA and offers customers an all-round package of up-to-
date communication interfaces combined with solid graphics and processing performance all
at a competitive price level. This combination makes the CP3003-V a perfect fit for industrial
automation applications such as visualization, machine control or inspection where the price is
often the crucial criterion.
The CP3003-V features the Intel® Celeron® 807UE processor (2
nd
Generation Celeron® tech-
nology) combined with the Mobile Intel® QM77 Express PCH. The 807UE Celeron® CPU of-
fers a good performance level at an extremely low power consumption plus a superior graphics
performance through the Intel® HD graphics core. On top of that, the QM77 PCH provides the
latest I/O interfaces such as USB3.0 or SATA 6Gb/s. The CPU board offers up to 4GB 1333
MHz DDR3 SDRAM with Error Checking and Correction (ECC).
On the system side, the CP3003-V supports a PCI 32-bit/33MHz CompactPCI® interface en-
abling the passive mode feature. When installed in a system master slot, the CompactPCI®
interface is enabled, whereas the CompactPCI® interface will be isolated when installed in a
peripheral slot.
The CP3003-V is an 8 HP CompactPCI® board equipped with an CP3003-HDD module and
comes as compact all-in-one solution that offers a comprehensive set of interfaces. At the front
panel a variety of communication interfaces such as one VGA, two DisplayPort, one USB 3.0,
two USB 2.0, three Gigabit Ethernet ports and a Serial port (RS-232) are available. Two SATA
6Gb/s interfaces and a CFAST socket, all realized as onboard connectors, complete the boards
I/O capabilities.
