Functional Description CP3003-SA
Page 2 - 20 ID 1052-6929, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
Table 2-14: 64-bit CompactPCI Connector J2 Pinout (CP3003-SA Front I/O Vers.)
PIN ROW Z ROW A ROW B ROW C ROW D ROW E ROW F
22 NC GA4 GA3 GA2 GA1 GA0 GND
21 NC CLK6 GND RSV RSV RSV GND
20 NC CLK5 GND RSV RSV RSV GND
19 NC GND GND RSV RSV RSV GND
18 NC RSV RSV RSV RSV RSV GND
17 NC RSV RSV PRST# REQ6# GNT6# GND
16 NC RSV RSV DEG# RSV RSV GND
15 NC RSV RSV FAL# REQ5# GNT5# GND
14 NC RSV RSV RSV RSV RSV GND
13 NC RSV RSV RSV RSV RSV GND
12 NC RSV RSV RSV RSV RSV GND
11 NC RSV RSV RSV RSV RSV GND
10 NC RSV RSV RSV RSV RSV GND
9 NC RSV GND RSV RSV RSV GND
8 NC RSV RSV RSV GND RSV GND
7 NC RSV RSV RSV RSV RSV GND
6 NC RSV RSV RSV GND RSV GND
5 NC RSV GND RSV RSV RSV GND
4 NC V(I/O) RSV RSV RSV RSV GND
3 NC CLK4 GND GNT3# REQ4# GNT4# GND
2 NC CLK2 CLK3 SYSEN# GNT2# REQ3# GND
1 NC CLK1 GND REQ1# GNT1# REQ2# GND
Note ...
The 64-bit CompactPCI signals are not used on the board and the 64-bit control
and address signals are not terminated to V(I/O).
