Troubleshooting
Appendices
Troubleshooting
If you experience problems, refer to the relevant item
and take the appropriate measures.
Power does not turn on
• Is the AC/AC power supply connected to an outlet?
☞p.13
• Is the [POWER] switch turned on?
Turn on the rear panel [POWER] switch. ........
☞p.17
Power is on, but nothing is displayed in the LCD
screen
• Perform the following procedure. (☞PG p.136)
1 Press the [EXIT] key three times, and press the
[GLOBAL] key.
2 Hold down the [EXIT] key, and press the
[WRITE] key.
3 Rotate the [VALUE] dial to adjust the LCD
screen.
No sound
• Are connections made correctly to your amp,
mixer, or headphones? ........................................
☞p.13
• Is your amp or mixer turned on?
• Is Local Control turned on?
In GLOBAL 2.1: MIDI, check the “Local Control
On” check box.............................................. PG
☞p.137
• Is the [VOLUME] slider raised? .................
☞p.7, p.15
• If there is no sound from the OUTPUT
(INDIVIDUAL) 1, 2 jacks, make sure that “BUS
Select (IFX/Indiv.Out Assign)” or “Bus Select”
following the insert effect is set to 1, 2, 1/2, . .
☞p.98~
• If specific tracks in Sequencer mode or Song
Play mode do not sound, Make sure that the
“PLAY/MUTE/REC” or “PLAY/MUTE” is set to
PLAY. ...........................................................
☞p.60, p.75
Make sure that the “Status” is INT or BTH.
.......................................................................
☞p.58, p.74
• Are the Key Zone and Velocity Zone set so that
sound will be produced when you play?
.................................................................... PG
☞p.52, 85
Notes do not stop
• In PROG 2.1: Ed–Basic, select the Prog Basic
page, make sure that the “Hold” check box is
unchecked........................................................
☞PG p.7
• In GLOBAL 6.1: Controller, make sure that
“Damper Polarity” or “Foot SW Polarity” is set
correctly.
........................................................................ PG
☞p.145
Noise or oscillation is heard
• When using the BPM/MIDI Sync function to
control the delay time of an effect, noise may occur
in the delay sound. This noise is due to
discontinuities in the delay sound, and is not a
malfunction.
Effects are not applied
• Are the GLOBAL 1.1: System, Basic page “IFX1–5
Off,” “MFX1 Off,” or “MFX2 Off” settings checked?
........................................................................
☞PG p.134
• If you are in Combination, Sequencer, or Song Play
modes, and master effects are not applied when
you raise the “S1 (Send1 (MFX1))” or “S2 (Send2
(MFX2))” of the timbre/track, does “Return 1” or
“Return 2” from the master effect need to be raised?
...................................................................
☞p.40, 67, 113
Alternatively, has “Send 1” or “Send 2” for each
oscillator of the program used by the timbre/track
been lowered? ........................................ PG
☞p.65, 111
The actual send level is determined by multiplying
the send setting of each oscillator in the program
with the send setting of the timbre/track.
Song does not playback correctly after data is
loaded
• In the dialog box when saving the data, did you
check the check boxes for each item that you
wanted to save?....................................................
☞p.41
• Are the program or combination banks/numbers
the same as when you created the song?
........................................................................ PG
☞p.136
Playback does not start when you press the
[START/STOP] key in Sequencer mode
• Is the GLOBAL 2.1: MIDI “Clock Source” set to
Internal?........................................................ PG
☞p.137
Can’t record in Sequencer mode
• Is the GLOBAL 1.1: Memory Protect “Song” check
box unchecked?............................................ PG
☞p.136
Is the GLOBAL 2.1: MIDI “Clock Source” set to
Internal? ........................................................ PG
☞p.137
