78| The Editor
Parameters Values Notes
Speed 1.00…10.00 Hz Adjusts the speed of the U-Vibe effect.
Depth 0…100 Adjusts the depth of the U-Vibe effect.
Mix 0…100 Adjusts the mix between the direct sound and the
effect. ‘0’ is no effect, ‘50’ is chorus, and ‘100’ is vi-
brato.
Vibrato
This effect simulates the chorus and vibrato circuitry (also called the Vibrato
Scanner) of a vintage organ. When the Preset mode is selected, the knobs
have no effect, and you can use the Type knob to select the type of vibrato
or chorus. When the Custom mode is selected, you can use the Depth and
Speed knobs to create either of these sounds, for an even broader range of
possibilities than the original unit! The Mix knob allows you to create vibrato
(pitch modulation) by outputting just the effect sound.
Parameters Values Notes
Mode Preset, Custom Selects either preset or custom settings.
Type V1, C1, V2, C2,
V3, C3
Selects the effect type when in Preset mode. V1/V2/
V3 are variations of vibrato, and C1/C2/C3 are vari-
ations of chorus (modeled after the original Vibrato
Scanner).
Vib/Ch Mix 0…100 When in Custom mode, sets the mix level between
Vibrato and Chorus.
Depth 0…100 When in Custom mode, adjusts the modulation depth.
Speed 0.02...20.00 Hz When in Custom mode, adjusts the modulation speed.
Mix 0…100 When in Custom mode, adjusts the mix between the
direct signal and the effect.
