page 98 Thermostatting the gas phase with the TJ20 (optional)
4. Insert the supplied measuring probe adapter into the measuring probe holder.
5. Insert the measuring probe into the measuring probe adapter. Move the sample
stage upward until the probe is located just above the liquid surface.
6. Place the two parts of the glass ring cover on the glass ring. The placed cover must
not touch the probe or the adapter!
7. The cover has a second opening for the temperature sensor. If available, fix the
sensor in its holder and lead it through the opening.
8. Set the desired temperature at the thermostat. Wait until the measuring
temperature has been reached before taking the measurement.
measuring
probe adapter
