page 22 Operating the instrument
4.3 The control panel (overview)
Measuring method selection, control of the measuring procedure and measuring
parameter input are carried out via the control panel. The height adjustment of the
sample vessel is also carried out via the control panel.
4.4 The display
The display is used for the dialog with the instrument.
• The current menu is indicated in the headline.
• The current temperature is always shown at the top right-hand side. The letter I or
E below the ° character indicates whether the temperature shown has been
measured by the sensor inside the thermostat vessel (I) or by the external sensor
(E).
• When the instrument is switched on or when one of the options ring method, plate
method or density determination is altered the central area shows a list of the set
parameters for the particular main menu. If the parameters are changed then the
individual points in the list are addressed in succession.
Display (ch. 4.4)
Height adjustment (outer ring;
ch. 4.5.2)
Keypad (ch. 4.6)
Special character input (inner
rotary knob; ch. 4.6.4)
