Data transfer to external media (optional) page 83
12.2.2 Preparations
Changing the output format
Connect the serial “RS-232” interface connection on the rear panel of the K11
(optionally: the USB port) to a referring interface on the computer.
Select the
Special Functions
menu (*-key) of the K11. Press the key (3) to switch
to LabDesk
output
.
Only for serial interface: Selecting the COM-port
1. Start LabDesk using the LabDesk icon on the Windows desktop or by using the
Windows start menu.
2. Click on the
Data-Logger
icon under the heading K11.
3. Under the menu item
Tools
Æ
Specific Preferences
select the tab sheet
Serial
Port
. Select the serial interface used.
!
The set baud rate of 9600 must not be altered.
