page 26 Operating the instrument
Key Functions
nos. 4,5,6 when entering parameters
letters G to O and nos. 4,5,6 when entering text
Main function: switching illumination on/off
Secondary functions: no. 7 when entering parameters
letters P,Q,R,S,7 when entering text
Main function: switching stirrer on/off
Secondary functions: no. 8 when entering parameters
letters T,U,V,8 when entering text
Main function: change to setup menu (basic settings)
Secondary functions: no. 9 when entering parameters
letters W,X,Y,Z,9 when entering text
Main function: changing the parameters in the current menu
Secondary functions: no. 0 when entering parameters
special characters when entering text
Decimal point when entering parameters
In the main menu of a measuring method starts the measurement.
When entering parameters: confirms the displayed or newly entered
parameter
Main function: jumps between main menu items (backwards)
Secondary function: deletes the character at the cursor position when
entering parameters and text
Jumps between the main menus (plate – ring – density – settings)
Accesses special functions (in combination with number keys)
When entering parameters (
Modify
) jumps to next or previous
parameter to be entered.
In the
Setup
menu: jumps to previous (
Prev.
) or
Next
page.
