6-8
Program Mode
V.A.S.T. and KB3 Programs
MIDI Control of KB3 Programs
Controller Numbers
Table 6‐3liststheMIDIControllernumbersthatcontrolKB3features.Sendthelistedcontroller
numberandappropriatecontrollervaluetocontroleachKB3featureviaMIDI.ThePC3LEalso
sendstheseControllernumberstoitsMIDIOutportwhenusingeachoftheseKB3features.
KB3 Program Feature
MIDI
Controller
Number
Values
Dist Drive (Mod Wheel) 1 0 = Minimum Distortion Drive.
127 = Maximum Distortion Drive.
Values between 0 and 127 scale between
minimum and maximum Distortion Drive.
Swell (CC/Volume/Expression Pedal) 11 0 = Minimum Swell.
127 = Maximum Swell.
Values between 0 and 127 scale between
minimum and maximum Swell.
Drawbar1 (Knob 1) 14 With Steps
parameter set to
(0-8)
(See Steps on page
6-61 for details)
With Steps
parameter set to
(0-127)
(See Steps on page
6-61 for details)
Drawbar2 (Knob 2) 15
Drawbar3 (Knob 3) 16
Drawbar4 (Knob 4) 17
Drawbar5 (Knob 5) 18 115-127 = volume 8
101-114 = volume 7
87-100 = volume 6
73-86 = volume 5
58-72 = volume 4
44-57 = volume 3
30-43 = volume 2
16-29 = volume 1
0-15 = volume 0
0 = minimum
volume.
127 = maximum
volume.
Values between 0
and 127 scale
between minimum
and maximum
volume.
Drawbar6 (Knob 6) 19
Drawbar7 (Knob 7) 20
Drawbar8 (Knob 8) 21
Drawbar9 (Knob 9) 22
Swell Ctl (Knob 10) 23 0 = Minimum Swell.
127 = Maximum Swell.
Values between 0 and 127 scale between
minimum and maximum Swell.
Leak Level (Knob 11) 24 0 = Minimum Leak Level.
127 = Maximum Leak Level.
Values between 0 and 127 scale between
minimum and maximum Leak Level.
Rotary Slow/Fast (Switch 1) 80 0-63 = Slow, 64-127 = Fast
Rotary Brake (Switch 2) 81 0-63 = Brake Off, 64-127 = Brake On
Chorus/Vibrato On/Off (Switch 3) 82 64-127 = On, 0-63 = Off
Chorus/Vibrato Select (Switch 4) 83 0-63 = Vibrato, 64-127 = Chorus
Chorus/Vibrato Depth (Switch 5) 85 0-42 = Depth 1, 43-85 Depth 2, 86-127
Depth 3
Percussion On/Off (Switch 6) 86 64-127 = On, 0-63 = Off
Percussion Level Loud/Soft (Switch 7) 87 64-127 = Loud, 0-63 = Soft
Percussion Decay Fast/Slow (Switch 8) 88 64-127 = Fast, 0-63 = Slow
Percussion Pitch High/Low (Switch 9) 89 64-127 = High, 0-63 = Low
KeyClick On/Off (Switch 10) 90 64-127 = On, 0-63 = Off
Table 6-3 KB3 MIDI Controller Assignments
