1775 IMU Technical Manual
11
Digital Data Output
Digital Data Output
The IMU provides a digital interface with the following characteristics:
Figure 9: Interface Characteristics
An idle line is always marking (in a binary 1 state). Thirty-six (36)
characters in sequence constitute a basic message with default settings.
For more information, refer to “Appendix C: Electrical Signaling ICD”
on page 31.
NOTE: The IMU’s RS422 RX signals are internally terminated to a nominal
impedance of 100
Data Output Signal Processing
For information about data output signal processing, refer to
“Appendix C: Electrical Signaling ICD” on page 31.
Parameter Value
Type RS422
Baud Rate Selectable: 9600, 19200, 38400, 57600, 115200,
460800, 576000, 921600 (default), 4147200
Parity None
Start Bits 1 (space, binary 0)
Data Bits 8 (1 message byte, starting with LSB)
Stop Bits 1 (mark, binary 1)
Flow Control None
