KVH Industries 1775 IMU User Manual

56-0298 Rev. B
This document contains proprietary information of KVH Industries, Inc. and neither this document nor said proprietary information shall be
published, reproduced, copied, disclosed, or used for any purpose without the express written permission of a duly authorized KVH
representative.
Page 20 of 77
Table 5-14: Test Results Byte 2
Datum
Bit Number
Notes
Accel Z Status
0 (16)
Reserved
1 (17)
Always 1
Gyro X SLD Temperature Status
2 (18)
Reserved
3 (19)
Always 1
Gyro Y SLD Temperature Status
4 (20)
Reserved
5 (21)
Always 1
Gyro Z SLD Temperature Status
6 (22)
Constant Zero
7 (23)
Always 0
Table 5-15: Test Results Byte 3
Datum
Bit Number
Notes
Accel X Temperature Status
0 (24)
Accel Y Temperature Status
1 (25)
Accel Z Temperature Status
2 (26)
GCB Temperature Status
3 (27)
IMU Temperature Status
4 (28)
GCB DSP SPI Flash Status
5 (29)
GCB FPGA SPI Flash Status
6 (30)
Constant Zero
7 (31)
Always 0
Table 5-16: Test Results Byte 4
Datum
Bit Number
Notes
IMU DSP SPI Flash Status
0 (32)
IMU FPGA SPI Flash Status
1 (33)
GCB 1.2V Status
2 (34)
GCB 3.3V Status
3 (35)
GCB 5V Status
4 (36)
IMU 1.2V Status
5 (37)
IMU 3.3V Status
6 (38)
Constant Zero
7 (39)
Always 0
Table 5-17: Test Results Byte 5
Datum
Bit Number
Notes
IMU 5V Status
0 (40)
IMU 15V Status
1 (41)
GCB FPGA Status
2 (42)
IMU FPGA Status
3 (43)
Hi-Speed SPORT Status
4 (44)
Aux SPORT Status
5 (45)
Sufficient Software Resources
6 (46)
Constant Zero
7 (47)
Always 0
