KVH Industries 1775 IMU User Manual

56-0298 Rev B
This document contains proprietary information of KVH Industries, Inc. and neither this document nor said proprietary information shall be
published, reproduced, copied, disclosed, or used for any purpose without the express written permission of a duly authorized KVH representative.
Page 17 of 77
Table 5-8: Status Byte Format
(Default binary data output format)
Function
Bit Number
Notes
Gyro X status
0 (LSB)
1 = Valid data, 0 = Invalid data
Gyro Y status
1
1 = Valid data, 0 = Invalid data
Gyro Z status
2
1 = Valid data, 0 = Invalid data
Reserved
3
Always 0
Accelerometer X status
4
1 = Valid data, 0 = Invalid data
Accelerometer Y status
5
1 = Valid data, 0 = Invalid data
Accelerometer Z status
6
1 = Valid data, 0 = Invalid data
Reserved
7
Always 0
NOTE: In addition to this general status information, an extended built-in test (BIT) may be initiated at any time
by entering the “?bit” command. (Extended BIT data is also output whenever the IMU is first powered on.) The
extended BIT provides six bytes of diagnostic data, which are defined in Table 5-12 through Table 5-19.
The constant zero bits are intentionally inserted in the status to prevent it from taking on a
value that, combined with the sequence number and temperature, could be misinterpreted as a
message header code.
Table 5-9: CRC Format
(Default binary data output format)
Parameter
Value
Width
32
Polynomial
0x04C11DB7
Reflect In
False
XOR In
0xFFFFFFFF
Reflect Out
False
Width
32
