KVH Industries 1775 IMU User Manual

56-0298 Rev B
This document contains proprietary information of KVH Industries, Inc. and neither this document nor said proprietary information shall be
published, reproduced, copied, disclosed, or used for any purpose without the express written permission of a duly authorized KVH representative.
Page 11 of 77
4 Data Communications and Unit Control
The 1775 IMU provides a digital interface for the following functions:
 Output of sensor data and status messages including built-in test messages.
 Receipt of external commands to configure and control the IMU assembly.
 Data output control, timing, and reset functions.
4.1 Interface Connector
The 1775 IMU is equipped with a type MIL-DTL-83513 15-pin (male-pin) Micro-D interface
connector for data communications and power. Table 4-1 below describes the function of each
pin. These were also shown in Figure 3-2.
Table 4-1: Electrical Interface Signals
Pin #
Number
Pin Name
Description
Comments
1
RS422-TX+
Output: differential
positive
RS-422 serial port for primary
data output and command input;
the commands that can be sent to
the RS-422 port are listed in
Section 7.2
2
RS422-TX-
Output: differential
negative
3
RS422-RX-
Input: differential negative
4
RS422-RX+
Input: differential positive
11
MSYNC+
Input: differential positive
Master Synchronization for
external data request
(see Section 10.3)
7
MSYNC-
Input: differential negative
13
CONFIG-RST-IN+
Input: differential positive
Configuration Reset
(see Section 10.1)
6
CONFIG-RST-IN-
Input: differential negative
14
EXT-RST+
Input: differential positive
External Reset
(see Section 10.2)
5
EXT-RST-
Input: differential negative
12
TOV-OUT+
Output: differential
positive
Time Of Validity (TOV)
(See Section 11)
8
TOV-OUT-
Output: differential
negative
10
POWER +
Power positive
10-32 VDC type; (9-36 VDC max)
(see Figure 3-2)
9
POWER -
Power return and signal
ground
15
NC
Do Not Connect
For factory/future use
