1775 IMU Technical Manual
i
Table of Contents
Table of Contents
Product Specifications.......................................................................1
Storage and Handling ........................................................................5
Maintenance......................................................................................5
Output Orientation .............................................................................6
Interface Connector ...........................................................................8
Interface Cable ..................................................................................9
Data Communications Equipment .....................................................9
Wiring the IMU .................................................................................10
Digital Data Output ..........................................................................11
Data Output Signal Processing ........................................................11
Message Structure ....................................................................12
Configuration Options................................................................14
Resetting Parameters to Factory Defaults.................................16
User Commands ..............................................................................17
Time of Validity (TOV) Output...........................................................18
Master Sync (External Data Request) ..............................................20
TOV with Internal MSYNC Mode ................................................21
TOV with External MSYNC Active...............................................21
Hardware Restart ............................................................................21
Mounting the IMU ............................................................................22
