KVH Industries 1775 IMU User Manual

56-0298 Rev B
This document contains proprietary information of KVH Industries, Inc. and neither this document nor said proprietary information shall be
published, reproduced, copied, disclosed, or used for any purpose without the express written permission of a duly authorized KVH representative.
Page 55 of 77
9 Configuration Options
The major configuration parameters are summarized in Table 9-1. All options are configurable
using the commands in Section 8. Axes of rotation and linear motion are shown in Figure 9-1.
Table 9-1: Configuration Options Summary
Parameter
Options
Default Value
Units
Configuration
Command
Baud rate
(1)
9600, 19200, 38400,
57600, 115200,
460800, 576000,
921600, 4147200
921600
Bd
(same as
bits/sec)
=BAUD to set
?BAUD to query
Data rate
(2)
1, 5, 10, 25, 50, 100,
250, 500, 750, 1000,
3600, 5000
1000
Hz
=DR to set
?DR to query
Output Format
A, B, C
A
N/A
=OUTPUTFMT to set
?OUTPUTFMT to query
Temperature
Units
ºC, ºF,
ºC_100, ºF_100
ºC
N/A
=TEMPUNITS to set
?TEMPUNITS to query
Angular Units
Radians, degrees
Radians
N/A
=ROTUNITS to set
?ROTUNITS to query
Rotational data
(gyro) format
Rate of rotation
(radians/sec or
degrees/sec) delta
angle
(3)
(radians or
degrees)
Delta angle
Varies by
option
=ROTFMT to set
?ROTFMT to query
X, Y, Z axis
definitions
(4)
Rotation matrix
(5)
from
reference axes shown
in Figure 9-1
1 0 0
0 1 0
0 0 1
N/A
=AXES to set
?AXES to query
Linear Units
Meters, Feet
Meters
N/A
=LINUNITS to set
?LINUNITS to query
Linear data
(accelerometer)
format
accelerometer, Delta
Acceleration in
g (g-force)
units
Acceleration
in g or delta-
velocity
=LINFMT to set
?LINFMT to query
Output filter
enable/disable
Enabled (1)
disabled (0)
Enabled
N/A
=FILTEN to set
?FILTEN to query
Output filter
type
Chebyshev,
Butterworth, Uniform
Averager, customer
defined 8
th
order filter
Chebyshev
(type II) filter
N/A
=FILTTYPE to set
?FILTTYPE to query
Output filter
coefficients
Infinitely configurable
8
th
order filter
coefficients
Chebyshev
(type II) filter
N/A
=FC20 to set
?FC20 to query
Output
Request
synchronization
Internal clock,
External request
(6)
Internal clock
(IMU mode)
N/A
=MSYNC to set
?MSYNC to query
