1775 IMU Technical Manual
2
Product Specifications
Performance: Accelerometers
KVH Part No.
01-0363-01
KVH Part No.
01-0363-25
Input Limit ±10 g max. ±25 g max.
Velocity Random Walk (room
temp.)
≤0.12 mg/√Hz
≤0.23 ft/sec/√h
≤0.007 mg/√Hz
≤0.023 ft/sec/√h
Input Axis Misalignment ±1 mrad ±1 mrad
Bandwidth (-3 dB) ≥200 Hz ≥450 Hz
Performance: Magnetometers
Input Range ±10 Gauss max. ±10 Gauss max.
Bias <0.2 Gauss <0.2 Gauss
Noise <2 mGauss <2 mGauss
Environment
Temperature (operating) -40°C to +75°C
(-40°F to +167°F)
-40°C to +75°C
(-40°F to +167°F)
Temperature (storage) -50°C to +85°C
(-58°F to +185°F)
-50°C to +85°C
(-58°F to +185°F)
Vibration (operating,
30 min/axis)
8 g rms (20-2000 Hz,
random)
peak acceleration level
limited to 10 g
15 g rms (20-2000 Hz,
random)
peak acceleration level
limited to 25 g
Vibration (non-operating) 12 g rms (20-2000 Hz,
random)
12 g rms (20-2000 Hz,
random)
Shock (operating) 9 g (11 ms, sawtooth) 25 g (11 ms, sawtooth)
Shock (non-operating) 40 g (11 ms, sawtooth) 40 g (11 ms, sawtooth)
Digital Data Output
Format RS422, Asynchronous, full differential
Data Rate 1 to 5000 Hz, user-selectable
Baud Rate 9600 to 4147200 baud, user-selectable
Initialization Time (room
temp.)
≤1.5 s (valid data)
Full Performance Time (room
temp.)
≤60 s typical
Total Motion-to-Output
Latency (max. baud and data
rates)
≤500 s
