Install the steering column and collar, then
tighten the nut.
Torque: 6.08.0kgf-m
Install the cotter pin and band ends of cotter
pin.
Install the tie rods and tighten the nut.
Torque: 4.05.0kgf-m
Install the cotter pin and band ends of cotter
pin.
Install handlebar and handlebar holder, then
tighten the four bolts.
Torque: 1.82.5kgf-m
Be sure that the ro
d
-end on the
indentation surface side is connected to
the steering column.

Always use a new cotter pin.

Always use a new cotter pin.

Indentation Surface
Bolts
Headlight Uni
t
Bolts
Handleba
r
Cotter Pin
Cotter Pin
Nu
t
Nu
t
Tie-rod
Cotter Pin
Nu
t
