4. LUBRICATION SYSTEM
4-6
MX’er SYSTEM
Screw
Inner Roto
r
Bolts
Pump Cove
r
Outer Roto
r
ASSEMBLY
Dowel Pin
Oil Pum
p
Arrow
Install the outer rotor, inner rotor and pump
shaft into the pump body.
Install the dowel pin.
Install the pump cover by aligning the hole
in the cover with the dowel pin.
Tighten the screw to secure the pump cover.
Make sure that the pump shaft rotates freely
without binding.
INSTALLATION
Install the oil pump into the crankcase.
After the oil pump is installed, tighten the
two mounting bolts.

Insert the pump shaft by aligning the flat
on the shaf at in the inner
rotor.
t with the fl

Install the oil pum
the pum
pump with engine oil before installation.
p with the arrow on
p body facing up and fill the oil
