Kyocera FS-3040MFP

2LW/2LX
1-5-3
1-5-2 Outer covers
(1) Detaching and refitting the right cover and left cover
Procedure
1. Remove the cassette. (See page 1-5-6)
2. Open the front cover.
3. Remove the one screw.
4. Unhook six hooks and then remove the
right cover.
Figure 1-5-3
Hook
Hook
Hook
Hook
Right cover
Hook
Front cover
Screw
Hook
