Kyocera FS-3040MFP

2LW/2LX
1-1-7
1-1-3 Machine cross section
Figure 1-1-3
Paper path
Paper path
(option)
Light path
10 9
13
12
78
54
6
2
13
14
11
1. Cassette
2. MP tray
3. Paper feed/conveying section
4. Toner container
5. Developing unit
6. Main charger unit
7. Drum unit
8. Laser scanner unit (LSU)
9. Transfer/separation section
10. Fuser unit
11. Rear unit
12. Eject section
13. Duplex/conveying section
14. Scanner unit
