2LW/2LX
1-5-25
1-5-5 Developing section
(1) Detaching and refitting the developing unit
Procedure
1. Open the front cover.
2. Remove the developing unit.
3. Check or replace the developing unit
and refit all the removed parts.
NOTE:
When the periodic maintenance
(replacing the maintenance kit, see
page 2-4-4), perform maintenance
mode.:
U251 Clearing the maintenance count
(see page 1-3-26)
Figure 1-5-40
Developing
unit
Front cover
To Next Page
