Kyocera FS-3040MFP

2LW/2LX
1-5-37
(3) Detaching and refitting the power source PWB
Procedure
1. Remove the right cover and left cover.
(See page 1-5-3)
2. Remove the drum unit.
(See page 1-5-26)
3. Remove three connectors from the
relay PWB.
4. Release three clamps and then remove
the wires.
Figure 1-5-57
YC2
YC1
YC3
Clamps
Reley PWB
Connectors
Wires
Clamp
