Kyocera FS-3040MFP

2LW/2LX
1-5-46
(3) Direction of installing the principal fan motors
When detaching or refitting the left fan motor or right fan motor, be careful of the airflow direction (intake or
exhaust).
Figure 1-5-69
Intake
Right fan motor
Left fan motor
(Rating label:inside)
Intake
(Rating label:inside)
