Kyocera FS-3040MFP

2LW/2LX
1-2-3
(2) Removing the tapes
<Procedure>
1. Remove the tape A.
2. Open the DP top cover.
3. Remove the tape B and then remove
the spacer.
4. Close the DP top cover.
Figure 1-2-3
5. Open the DP.
6. Remove the sheet.
7. Remove the paper.
Figure 1-2-4
Tape B
DP top cover
Tape A
Spacer
DP
Sheet
Paper
