2LW/2LX
1-5-9
6. Remove the lower registration roller.
7. Remove the stopper, gear and three
bushes from the lower registration
roller.
8. Check or replace the upper registration
and lower roller and refit all the
removed parts.
Figure 1-5-12
Bush
Gear
Stopper
Lower registration roller
Bush
Bush
To Next Page
