2LW/2LX
1-5-17
10. Remove two fulcrum of the upper cover.
Figure 1-5-24
11. Remove six screws on the top tray.
12. Remove the top tray.
Figure 1-5-25
Fulcrum
Fulcrum
Upper cover
Screw
Top tray
Screw
Screw
Screw
Screw
Screw
