2LW/2LX-2
1-1-2
Image write system Semiconductor laser (1 beam)
Charging system Contact charger roller method (positive charging)
Developing system Mono component dry developing method
Toner replenishing: Automatic from the toner container
Transfer system Transfer roller (negative-charged)
Separation system Small diameter separation, discharger brush (negative-charged)
Cleaning system Counter blade cleaning + cleaning roller
Charge erasing system Exposure by eraser lamp (LED)
Fusing system Heat roller system
Heat source: halogen heater
Abnormally high temperature protection devices: thermostat
CPU PowerPC440 (667MHz)
Memory Standard 256MB
Maximum 768MB
Interface USB: 1 port (Hi-speed USB 2.0)
USB host: 1 port
Ethernet: 1 port (10BASE-T/100BASE-TX)
Resolution 600×600 dpi
Operating
environment
Temperature 10 to 32.5 °C/50 to 90.5 °F
Humidity 15 to 80%
Altitude 2,500 m/8,202 ft maximum
Brightness 1,500 lux maximum
Dimensions (W × D× H) 494 × 497.1 × 545.5 mm
19 7/16” × 19 9/16” × 21 1/2”
Weight 3in1 model (without FAX): Approx. 25.5 kg / 56.2 lbs
4in1 model (with FAX) : Approx. 25.8 kg / 56.9 lbs
Space Space required
(W × D)
Without MP tray: 494 × 497.1 mm
19 7/16” × 19 9/16”
With MP tray : 494 × 656.1 mm
19 7/16” × 25 13/16”
Power source 120 V AC, 60 Hz, more than 10.0 A
220 - 240 V AC, 50/60 Hz, more than 6.0A
Options Paper feeder × 3, Expanded memory
Item Specifications
