2LW/2LX
1-5-44
9. Remove three screws and then remove
the paper feed drive unit.
10. Check or replace the paper feed drive
unit and refit all the removed parts.
To refit the paper feed drive unit, make
sure mesh of gears.
Figure 1-5-67
Gear
Gear
Screw
Screw
Screw
Paper feed
drive unit
Paper feed
drive unit
