Kyocera FS-3040MFP

2LW/2LX
2-3-2
Connector Pin Signal I/O Voltage Description
YC101 1 LIVE I 120 V AC
220-240 V AC
AC power input
Connected to
AC inlet and
main power
switch
2 NEUTRAL I 120 V AC
220-240 V AC
AC power input
YC102 1 COMMON1 O 120 V AC/0V
220-240 V AC/0V
FH: On/Off
Connected to
relay PWB
2N.C -- Not used
3 LIVE O 120 V AC220-240
V AC
AC power to RYPWB
YC103 1 +5V1 O 5 V DC 5 V DC power to CPWB-L
Connected to
connect-L
PWB
2 +5V1 O 5 V DC 5 V DC power to CPWB-L
3 +5V1 O 5 V DC 5 V DC power to CPWB-L
4 +24V1 O 24 V DC 24 V DC power to CPWB-L
5 HUNITN O 0/5 V DC EVFSW: On/Off
6 HANDSN O 0/5 V DC MPPS: On/Off
7 N.C. - - Not used
8 HEATONN1 I 0/5 V DC FH: On/Off
9 ZCROSS O 0/5 V DC (pulse) Zero-cross signal
10 SWSLEEPN I 0/5 V DC Sleep mode signal: On/Off
11 +24V2 O 24 V DC 24 V DC power to CPWB-L (via ILSW)
12 GND - - Ground
13 GND - - Ground
14 GND - - Ground
15 GND - - Ground
16 +24V2 O 24 V DC 24 V DC power to CPWB-L (via ILSW)
17 +24V2 O 24 V DC 24 V DC power to CPWB-L (via ILSW)
