Kyocera FS-3040MFP

2LW/2LX
2-3-15
Connector Pin Signal I/O Voltage Description
YC1 1 +24V2 I 24 V DC 24 V DC power from PSPWB (via ILSW)
Connected to
power source
PWB
2 +24V2 I 24 V DC 24 V DC power from PSPWB (via ILSW)
3 GND - - Ground
4 GND - - Ground
5 GND - - Ground
6 GND - - Ground
7 +24V2 I 24 V DC 24 V DC power from PSPWB (via ILSW)
8 SWSLEEPN O 0/5 V DC Sleep mode signal: On/Off
9 ZCROSS I 0/5 V DC (pulse) Zero-cross signal
10 HEATONN1 O 0/5 V DC FH: On/Off
11 N.C. - - Not used
12 HANDSN I 0/5 V DC MPPS: On/Off
13 HUNITN I 0/5 V DC EVFSW: On/Off
14 +24V1 I 24 V DC 24 V DC power from PSPWB
15 +5V1 I 5 V DC 5 V DC power from PSPWB
16 +5V1 I 5 V DC 5 V DC power from PSPWB
17 +5V1 I 5 V DC 5 V DC power from PSPWB
YC2 1 +24V1 O 24 V DC 24 V DC power to paper feeder
Connected to
paper feeder
2 OPSCLK O 0/5 V DC (pulse) Serial communication clock signal
3 +5V1 O 5 V DC 5 V DC power to paper feeder
4 OPRDYN I 0/5 V DC Paper feeder ready signal
5 OPSEL0 O 0/5 V DC Paper feeder select signal (0)
6 OPSEL1 O 0/5 V DC Paper feeder select signal (1)
7 OPSEL2 O 0/5 V DC Paper feeder select signal (2)
8 OPSDI I 0/5 V DC (pulse) Serial communication data signal input
9 OPSDO O 0/5 V DC (pulse) Serial communication data signal output
10 GND - - Ground
YC3 1 GND - - Ground
Connected to
drum PWB
2 ERASER O 0/24 V DC CL: On/Off
3 GND - - Ground
4 WTNLEDN O 0/5 V DC (pulse) WTS (light emission) control signal
5 EECLK O 0/5 V DC (pulse) DRPWB clock signal
6 WTNFUL I 0/5 V DC (pulse) WTS detection signal
7 EEDIO I/O 0/5 V DC (pulse) DRPWB EEPROM data signal
8 +5V2 O 5 V DC 5 V DC power to DRPWB
9 GND - - Ground
10 +5V2 O 5 V DC 5 V DC power to DRPWB
