Kyocera Mita FS-1128MFP Service Manual

2JN
2-3-7
YC20 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the regis-
tration
clutch,
paper feed
clutch and
developing
clutch
2 REGDRN O 0/24 V DC Registration clutch: On/Off
3 +24V3 O 24 V DC 24 V DC power source
4 FEDDRN O 0/24 V DC Paper feed clutch: On/Off
5 +24V3 O 24 V DC 24 V DC power source
6 DLPDRN O 0/24 V DC Developing clutch: On/Off
YC21 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the MP
paper feed
solenoid
2 MPFDRN O 0/24 V DC MP paper feed solenoid: On/Off
YC23 1 +24V1 I 24 V DC 24 V DC power source
Connected
to the high
voltage
PWB
2 +3.3V1 O 3.3 V DC 3.3 V DC power source
3 ZCROSS I 0/3.3 V DC (pulse) Zero cross signal
4 FAN O 0/24 V DC Left cooling fan motor: On/Off
5 HEATN O 0/3.3 V DC Fuser heater lamp: On/Off
6 SLEEP O 0/3.3 V DC Sleep mode signal: On/Off
7 MHVDR O 0/3.3 V DC Main charger output signal: On/Off
8 RTHVDR O 0/3.3 V DC Transfer (reverse) bias output signal: On/Off
9 PSEL1 O 0/3.3 V DC Transfer (reverse) bias control signal: On/Off
10 HVCLK O 0/3.3 V DC (pulse) Developing bias clock signal
11 REGN I 0/3.3 V DC Registration sensor: On/Off
12 TCNT O PWM Transfer current control signal
13 MCNT O PWM Main charger output control signal
14 THVDR O 0/3.3 V DC Transfer bias output signal: On/Off
15 CASE I Analog Cassette switch: On/Off
16 THERM I Analog Fuser thermistor detection voltage
17 +24V3 O 24 V DC 24 V DC power source
18 SGND - - Ground
19 SEPA - - -
YC24 1 +3.3V1 O 3.3 V DC 3.3 V DC power source
Connected
to the waste
toner sensor
2 TNFULL I 0/3.3 V DC Waste toner full detection signal
3 SGND - - Ground
YC25 1 +24V2 I 24 V DC 24 V DC power source
Connected
to the high
voltage
PWB
2 +24V2 I 24 V DC 24 V DC power source
3 PGND - - Ground
4 PGND - - Ground
YC26 1 +3.3V1 O 3.3 V DC 3.3 V DC power source
Connected
to the toner
sensor
2 TEMPTY I 0/3.3 V DC Toner quantity detection signal
3 SGND - - Ground
YC27 1 +24V1 O 24 V DC 24 V DC power source
Connected
to the right
cooling fan
motor
2 FAN O 0/24 V DC Right cooling fan motor: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera Mita FS-1128MFP Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet
Monthly Duty Cycle	20, 000 pages
Functions	Print, Copy, Scan, Fax
Fax Transmission Speed	33.6 Kbps
Print Speed	28 ppm
Copy Speed	28 cpm
Standard Paper Capacity	250 sheets
Automatic Document Feeder (ADF)	50 sheets
