Kyocera Mita FS-1128MFP Service Manual

2JN
2-3-8
YC28 1 ERASER O 0/24 V DC Eraser lamp: On/Off
Connected
to the eraser
lamp
2 ERASRW O 24 V DC 24 V DC power source
YC29 1 DUDR1 O 0/24 V DC Duplex solenoid (activate): On/Off
Connected
to the
duplex sole-
noid
2 COMMON O 24 V DC 24 V DC power source
3 DUDR2 O 0/24 V DC Duplex solenoid (return): On/Off
YC30 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the
optional
paper feeder
(PF main
PWB)
2 PGND - - Ground
3 PFSI I 0/3.3 V DC (pulse) Serial communication data input signal
4 PFSO O 0/3.3 V DC (pulse) Serial communication data output signal
5 PSEL O 0/3.3 V DC Paper feeder selection signal
6 +3.3V1 O 3.3 V DC 3.3 V DC power source
Connector Pin Signal I/O Voltage Description

Kyocera Mita FS-1128MFP Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet
Monthly Duty Cycle	20, 000 pages
Functions	Print, Copy, Scan, Fax
Fax Transmission Speed	33.6 Kbps
Print Speed	28 ppm
Copy Speed	28 cpm
Standard Paper Capacity	250 sheets
Automatic Document Feeder (ADF)	50 sheets
