EMG 8500 Hardware Components
Figure 2-4 EMG 8500 Unit (front side)
Figure 2-5 EMG 8500 Unit (back side)
DIO Port Micro
SD Card
LEDs
Console Port
USB Port
The appearance and function of the EMG unit will depend
upon the type(s) of I/O modules installed in the bays.
Two I/O Module Device
Port Bays
The EMG supports the use of single mode and
multi-mode fiber optic SFP transceiver modules.
SFP modules are purchased separately.
The appearance and function of the EMG unit will
depend upon the type(s) of connectivity modules
installed in the bays.
Two Connectivity Module Bays
Dual Ethernet and
SFP Ports
Power inlet
