7: Networking

EMG™ Edge Management Gateway User Guide 92

Ethernet Counters

The Network > Network Settings (1 of 2) page displays statistics for each of the EMG Ethernet

ports since boot-up. The system automatically updates them.

Note: For Ethernet statistics for a smaller time period, use the diag perfstat

command.

Network Commands

Go to Network Commands to view CLI commands which correspond to the web page entries

described above.
