8: Device Ports
SLC™ Console Manager User Guide 103
SLP Commands
2. Click the Apply button.
Device Port - Sensorsoft Device
Devices made by Sensorsoft are used to monitor environmental conditions.
1. In the Connected to field above the IP Settings section of the Device Port Settings page,
select Sensorsoft.
2. Click the Device Commands link. The following page displays:
Figure 8-7 Devices > Device Ports > Sensorsoft
3. Select a port and enter or view the following information:
Environmental Status Click the link to view the environmental status (e.g., temperature and humidity).
Infeed Status Click the link to view the status of the data the SLP unit or ServerTech CDU is
receiving.
System Info Click the link to see system information pertaining to the SLP unit or
ServerTech CDU.
Restart SLP To restart the SLP device or ServerTech CDU, select the checkbox.
Control Outlet For Tower A or Tower B, select All Outlets or Single Outlet and the number
of the outlet to be controlled (1-8 for the SLP8 or 1-16 for the SLP16) and select
the command for the outlet (No Action, On, Off, Cycle Power). No Action is
the default.
Dev Port Displays the number of the SLC port.
Device Port Name Displays the name of the SLC port.
Temp Current temperature (degrees Celsius) on the device the sensor is monitoring.
Low Temp Enter the temperature (degrees Celsius) permitted on the monitored device below
which the SLC console manager sends a trap.
High Temp Enter the temperature (degrees Celsius) permitted on the monitored device above
which the SLC unit sends a trap.
Use °F Display and set the temperature for this device in degrees Fahrenheit, instead of
Celsius, which is the default.
Humidity (%) Current relative humidity on the device the sensor is monitoring.
