LeCroy WaveAce series User Manual

Getting Started Manual
WA-GSM-E RevB
vi
Trigger Types ................................................................ 45
Edge Triggering ............................................................ 45
Pulse Triggering ........................................................... 46
Video Triggering ........................................................... 48
Slope Triggering ........................................................... 49
Alternative Triggering .................................................. 50
Analyzing Waveforms ................................................... 51
Waveform Measurements ........................................... 51
Measuring with Cursors ............................................... 51
Parameter Measurements ........................................... 54
Waveform Math .......................................................... 58
Waveform Math Overview .......................................... 58
FFT ................................................................................ 59
Creating Reference Waveforms ................................... 60
Creating Reference Waveforms ................................... 60
Save and Recall ............................................................. 63
Saving and Recalling Oscilloscope Setups .................... 63
Saving the Current Settings ......................................... 63
Recalling Setups ........................................................... 64
Saving and Recalling Waveforms ................................. 65
Saving Waveforms ....................................................... 65
Recalling Waveforms ................................................... 66
Saving Data as a .CSV File ............................................ 67
Saving a .CSV file .......................................................... 67
Saving and Printing Waveform Pictures ...................... 68
Recalling Factory Settings ............................................ 70
Using the SAVE ALL Screen .......................................... 75
Recalling Files ............................................................... 76

LeCroy WaveAce series Specifications

General

Channels	2 or 4
Vertical Resolution	8-bit
Input Coupling	AC, DC, GND
Power Supply	100-240 VAC, 50/60 Hz
Sample Rate	2 GS/s
Display	800 x 480
Input Impedance	1 MΩ
Timebase Range	5 ns/div to 50 s/div
Trigger Types	Edge, Pulse Width, Video, Slope
Connectivity	USB host, USB device
