LeCroy WaveAce series User Manual

WaveAce Series
vii
WA-GSM-E RevB
Page 2/2 ....................................................................... 76
Creating Folders and Files ............................................ 77
Utilities ......................................................................... 78
Utility Menu ................................................................. 78
Utility Menu - Page 1/4 ................................................ 78
Utility Menu - Page 2/4 ................................................ 79
Utility Menu- Page 3/4 ................................................. 83
Utility Menu- Page 4/4 ................................................. 85
System Status ............................................................... 85
Print Setup .................................................................... 87
Print - Page 1/2............................................................. 87
Print - Page 2/2............................................................. 88
Updating the System Software .................................... 88
Using Pass/Fail .............................................................. 91
Pass/Fail - Page 1/2 ...................................................... 91
Pass/Fail - Page 2/2 ...................................................... 93
Using Record ................................................................ 95
The Record Menu (with Mode Set to Record) ............. 96
Reference ..................................................................... 99
WaveAce Specifications ............................................... 99
CERTIFICATIONS ........................................................... 99
CE Declaration of Conformity ....................................... 99
EMC Directive ............................................................... 99
Low-Voltage Directive ................................................ 100
UL and cUL .................................................................. 101
Contact LeCroy for Support ........................................ 101
Index ........................................................................... 103

LeCroy WaveAce series Specifications

General

Channels	2 or 4
Vertical Resolution	8-bit
Input Coupling	AC, DC, GND
Power Supply	100-240 VAC, 50/60 Hz
Sample Rate	2 GS/s
Display	800 x 480
Input Impedance	1 MΩ
Timebase Range	5 ns/div to 50 s/div
Trigger Types	Edge, Pulse Width, Video, Slope
Connectivity	USB host, USB device
