LeeBoy Model 8510B Conveyor Paver 8-7
Troubleshooting
Optimize Dual Joystick Steering
Control Box:
Adjustment should only be done by an
Authorized LeeBoy Dealer.
1. Turn the paver off. Open the dash board panel and
locate the Optimize/Calibrate connector and plug it
into the Optimize receptacle.
2. Place all joysticks in the center position and move
the RUN/STOP switch(es) into the STOP position.
3. Turn the power key to the on position (power to
the Plus One controller). Outputs are disabled.
The status light will blink a slow continuous blink to
indicate Optimize Mode.
4. Wait 5 seconds for the Plus One to capture the
joysticks in center (NEUTRAL) position.
5. Push joysticks full FORWARD for 5 seconds.
6. Push joysticks full REVERSE for 5 seconds.
7. If a second control box is present optimize it in the
same manner.
8. The status light will stop blinking. Unplug the
Optimize/Calibrate connector from the Optimize
receptacle and turn off the power key.
Calibrate Dual Joystick Control
Box:
Calibration (also called straight line tracking) involves
4 steps: Threshold, low, mid and high speed setting.
There are separate procedures for calibrating pavers
with Dual Joystick steering control and Steering wheel
with FNR Joystick steering control. On pavers with two
steering control boxes the calibration will only need to
be done with one box.
NOTE: This procedure will set the maximum speed of
the paver.
To calibrate the dual joystick steering control box:
1. Turn the paver off.
2. Open the dash board panel and locate the Optimize/
Calibrate connector and plug it into the Calibrate
receptacle.
3. Place all joysticks in the center (NEUTRAL) position
and move the RUN/STOP switch into the RUN
position. If two control boxes are present place the
other RUN/STOP switch to the STOP position.
4. Turn paver on and the status light will blink rapidly
with no pauses to indicate Calibration Mode.
Setting The Threshold:
1. Start the engine and run at 1/2 throttle.
2. Move left joystick FORWARD until paver begins to
move slightly, then toggle RUN/STOP switch from
RUN to STOP and back to RUN. Return joystick to
NEUTRAL.
3. Move left joystick REVERSE until paver begins to
move slightly, then toggle RUN/STOP switch from
RUN to STOP and back to RUN. Return joystick to
NEUTRAL.
4. Move right joystick FORWARD until paver begins to
move slightly, then toggle RUN/STOP switch from
RUN to STOP and back to RUN. Return joystick to
NEUTRAL.
5. Move right joystick REVERSE until paver begins to
move slightly, then toggle RUN/STOP switch from
RUN to STOP and back to run. Return joystick to
NEUTRAL.
