5
LeeBoy Model 8510B Conveyor Paver 5-7
Component Location
ITEM NO. CONTROL NAME FUNCTION
17 Left Conveyor
Automatic/Manual
Selects automatic or manual override for left conveyor.
Center is OFF position.
For Automatic operation set switch to AUTOMATIC position.
MANUAL position provides override.
18 Throttle Switch Used to set the engine RPM. Push THROTTLE up for higher RPM. Push
THROTTLE down for lower RPM.
19 Ignition Controls starting, stopping, and running of engine.
Vertical position is OFF. Turn key right one notch for power. Red light will
illuminate.
Turn key to left to pre-heat engine.
Far right is the START position. After engine starts, release key, which will
automatically return to the power position.
Use protective cover when not in use.
NOTE: Engine will not start unless machine is in NEUTRAL.
20 Plus One Indicator Light Illuminates when there is a fault code in the Plus One system.
See Maintenance section for more information.
21 Parking Brake Sets brake in drive torque hub.
Move switch to ON position to activate brake.
Move switch to OFF to deactivate brake and allow paver movement.
Table 5-2. Main Dash Panel (continued)
