10-124 LeeBoy Model 8510B Conveyor Paver

Illustrated Parts List (IPL)

Alphabetical Parts Index

Description Part Number Figure Number Item Number

#10 Hose Clamp .375 to .625 33164 10-10 —

#10-32 x .750 serrated ange bolt Reference 10-9 —

#28 Hose Clamp 1.25 to 1.75 33169 10-10 —

#4 Hose Clamp .250 to .625 33277 10-10 —

#40 Hose Clamp 2.00 to 2.50 33437 10-10 —

#44 Hose Clamp 2.25 to 2.75 700500 10-10 —

#48 Hose Clamp 2.50 to 3.00 871111527 10-10 —

.250-20 nylock nut 80350 10-9 —

.250-20 serrated nut Reference 10-9 —

.250-20 x .500 serrated ange bolt Reference 10-9 —

.250-20 x .625 serrated ange bolt Reference 10-9 —

.250-20 x 1.25 hex head bolt 80187 10-9 —

.250-20 x 1.50 hex head bolt 80194 10-9 —

.313 x .125 Barb Tite Hose End 33491 10-10 —

.313 x .250 Male Pipe Elbow 38279 10-10 —

.313-18 x .750 serrated ange bolt Reference 10-9 —

.375 lock washer 80162 10-9 —

.375 SAE at washer 80996 10-9 —

.375 x 2.00 fender washer 512156 10-9 —

.375-16 serrated ange nut Reference 10-9 —

.375-16 x .750 serrated ange bolt Reference 10-9 —

.375-16 x 1.00 bolt 80221 10-9 —

.375-16 x 1.00 serrated ange bolt 104-205-1A 10-9 —

.375-16 x 1.25 serrated ange bolt Reference 10-9 —

.375-16 x 2.00 serrated ange bolt Reference 10-9 —

.375-16 x 2.25 serrated ange bolt Reference 10-9 —

.375-16 nut 80038 10-9 —

.375-24 hex nut 80056 10-9 —

12" Auger Ext, LH 985795 10-5 —

12" Auger Ext, RH 985796 10-5 —

800 Ex Elbow w/Flange 3Hole 1002917-06 10-10 6

804 Fan Spacer 1002917-20 10-10 19

Actuator, Emulsion Throttle, DC 12v 987985 10-9 32

Actuator, Emulsion Throttle, DC 12v 987985 10-10 37

Adapter, .250-18 Fp To M14 1002917-26 10-10 —

Adapter, .500-20 to .250-18 SAE 1002917-25 10-10 —

Adapter, Hose to Pipe (90 deg) 230069 10-13 12

Adapter, Hyd. Hose 2404-10-8 10-1 32
