4-6 LeeBoy Model 8510B Conveyor Paver
Specications
Table 4-8. Lubricant Specications
ITEM SPECIFICATION
Engine Oil 15W-40, API CH-4, CI-4
Hydraulic Oil All Weather 68
Torque Hub 50 WT Gear Oil
Grease Shell Avania EP Grease or Equivalent
Chain Lube Chain Lube
Table 4-9. Screed Specications
ITEM SPECIFICATION
Extensions Two 42 inch hydraulically operated extensions
Vibration Two hydraulic vibrators producing 3400 vibrations per
minute
Crown/Valley Adjustable, at least 2 inches of crown and 1-1/2 inches of
valley
Extensions Includes a level indicator
Propane Heat Two (2) 54,000 BTU propane burners on main screed
One (1) 54,000 BTU propane burner on each extension
Electric Heat (Option) Two (2) Electric Heat Elements (3412 BTU/hr) on main
screed
One (1) Electric Heat Element (3412 BTU/hr) on each
extension
Dimensions
Paver Overall Dimensions
Figure 4-1
