LeeBoy Model 8510B Conveyor Paver 6-5
Operation
Stopping the Engine
1. Throttle back to idle by pushing the throttle switch
down (Figure 5-2,18) until idle speed is reached.
2. Turn ignition key on instrument panel
counterclockwise (CCW) to the OFF position and
remove key.
Activating and Deactivating
Operator Control Station
Operation Hazard! Never leave
machine operator station unattended with machine
in gear and/or in motion. Operator station is dened
as the platform area within arms reach of active
control steering box. Operator must remain in
operator’s station at all times when machine is in
gear and/or in motion. Before leaving machine
operator station, operator must return joysticks to
neutral position and move RUN/STOP switch to
STOP position.
NOTE: The paver can operate using only one operator
station at a time. Paver is typically operated from
Left Operator Station.
1. If operator intends to change active operator station
(i.e. from left side to right side), operator must rst
return joystick(s) to NEUTRAL position and move
RUN/STOP switch to STOP position.
2. Operator can then move to other operator station
and activate by moving RUN/STOP switch to RUN
position.
Paver Driving
Instructions
Rapid counter-rotation in either
direction, clockwise or counterclockwise could
result in operator being thrown from machine
resulting in personal injury or death. Counter-
rotation is dened as either one joystick in extreme
forward position and opposite joystick in extreme
rear position, or steering wheel is in extreme right or
left turn position while machine is in gear and moving
forward or reverse. Make only slow adjustments to
joysticks or steering wheel to turn machine.
Electronic Control Steering Box
NOTE: You can only use one steering control module at
a time. When steering paver with control module
the RUN/STOP Switch (Figure 6-1,4; Figure
6-2,3) must be in RUN position on the module in
use and STOP position on the other module not
in use.
NOTE: To slow the unit, move joystick closer to
NEUTRAL or from NEUTRAL to STOP.
NOTE: To stop paver, pull joystick back to the neutral
position or use RUN/STOP switch on active
console. When switch is set to RUN, paver
resumes prior speed.
Steering Wheel Option
To drive the paver, point the steering wheel (Figure
6-1,2) straight ahead and lift up on the neutral lock
(Figure 6-1,3) on joystick (Figure 6-1,1). Push the
joystick (lever) forward slowly to reach the desired
speed and turn the steering wheel (Figure 6-1,2) slowly
to make turns as desired. The more you move the
joystick the faster the travel speed.
1. After the paver has been started and the engine is
warmed up, paver movements may be made.
Before starting forward with paver
make certain that no one is in front of the paver.
